High Efficiency Rotary Drum Dryer for Slag, coal, wood, bagasse
| Payment Terms: | T/T,L/C |
| Place of Origin: | Henan, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
1.Material:carbon steel2.10 years manufacturer3.Saving 10% energy
High Efficiency Rotary Drum Dryer for Slag, coal, wood, bagasse
Specifications
1.Material:carbon steel
2.10 years manufacturer
3.Saving 10% energy
2.10 years manufacturer
3.Saving 10% energy
Introduction
Rotary dryer machine is widely used for drying materials in the industries of cement, mine, construction, chemical,compound fertilizer, etc. Feeding and discharging unit is installed with thermocouple to control drier temperature. The temperature change of drier's feeding end can be indicated by the thermometer to control the inner drier temperature
rotary drum dryer is handling by bringing it into direct contact with a heated gas. The dryer is made up of a large, rotating cylindrical tube,The dryer slopes slightly so that the discharge end is lower than the material feed end in order to convey the material through the dryer under .
Application
Rotary drum Dryer Machine is widely used in building materials, metallurgy, chemical industry and cement industry, which is widely used to dry the stuff such as limestone, coal powder, slag and clay.
Rotary drum Dryer Machine is widely used in building materials, metallurgy, chemical industry and cement industry, which is widely used to dry the stuff such as limestone, coal powder, slag and clay.
Features
1) Rotary drier/dryer with professional design
2) Low energy consumption
3) Long life span; Simple structure
4) Low cost and high output
5) Automatic operation
6) High capacity and efficiency
Parameters
Model | Capacity t/h | Drum rolling speed | Motor –kw | Finished product moisture | Instal angle | Weight /t |
Φ0.65×10m | 1.5 | 3-5r/min | 5.5 | <15% | 3-5 | 13.5 |
Φ1.2×10m | 2.5 | 3-5r/min | 7.5 | <15% | 3-5 | 13.5 |
Φ1.5×12m | 3.3-4.9 | 3-5r/min | 10 | <15% | 3-5 | 18.9 |
Φ1.5×15m | 4-6 | 3-5r/min | 18.5 | <15% | 3-5 | 21 |
Φ1.8×12m | 4-6 | 3-5r/min | 11 | <15% | 3-5 | 22.83 |
Φ2.2×12m | 7-12 | 3-5r/min | 18.5 | <15% | 3-5 | 37.6 |
Φ2.2×14m | 7-12 | 3-5r/min | 18.5 | <15% | 3-5 | 40 |
Φ2.2×16m | 12 | 3-5r/min | 30 | <15% | 3-5 | 45 |
Φ2.4×14m | 12 | 3-5r/min | 30 | <15% | 3-5 | 51 |
Φ2.4×18m | 10-13 | 3-5r/min | 37 | <15% | 3-5 | 54 |
Φ2.4×20m | 10-14 | 3-5r/min | 37 | <15% | 3-5 | 54.14 |
Φ3×20m | 25 | 3-5r/min | 55 | <15% | 3-5 | 78 |
Φ3×25m | 32-36 | 3-5r/min | 75 | <15% | 3-5 | 104.9 |
